Cameras

One of the most critical components of an imaging system, cameras are the eyes of your application.  Selecting the right camera can be difficult as there are many vendors and hundreds of variations to choose from.  We are here to help you sort through all of this put the best product in your hands.

Photonfocus AG (Lachen, Switzerland) combines solely leading expertise in designing CMOS sensors with sound vision camera engineering. Photonfocus sells standard cameras and OEM vision modules for the industrial market. Besides standard products Photonfocus offers solutions adapted at customer's needs.

Systematic Vision is the lead Distributor in North America for the complete line of Photonfocus CMOS cameras, smart cameras, 3D cameras, board level cameras, OEM modules and sensors.

Please CONTACT US if you require any additional information or would like a quotation. We will be more than happy to assist you directly or put you in touch with one of our local Photonfocus Distribution Partners.

Applications: Quality Control, Process Control, Welding, ITS & Security, Motion Analysis, Automotive, Medical, Research

Quick Links: MV1-D2048x1088-3D03, DR1-D1312-200-G2-8, MV1-D2080-160-CL-12,
MV1-D1312-CL Series, MV1-D1312-G2 Series, MV-D1024E Series

Key features of Photonfocus cameras:

Photonfocus sensors

High Dynamic Range with proprietary LinLog® - up to 120dB

Global Shutter

Wide spectral range

NO sensor cover glass

High full well capacity and SNR

Configurable region of interest (ROI)

Up to 512 regions of interest (MROI) and decimation

2 look-up tables (12-to-8 bit) on user-defined image region (Region-LUT)

3x3 convolver for image pre-processing in the camera

Integrated digital reduction of fix pattern noise (FPN)

Integrated shading correction

Temperature monitoring of sensor and camera

Crosshairs overlay on the image

Ultra low trigger delay and jitter

Multiple trigger modes

Strobe output

D2080 Special Series > Coming Soon!
MV1-D2048 Series > Coming Soon!
MV1-D2048x1088 Series > Coming Soon!

MV1-D2048x1088-3D03 > Brochure

The Photonfocus 3D CMOS camera MV1-D2048x1088-3D03-160-G2-8 was developed for Laser triangulation systems with high triangulation rates. The CMOSIS CMOS sensor CMV2000 features a full well capacity (FWC) of 13.5 ke- optimized for high sensitivity is combined with a robust algorithm for line peak detection.

An onboard high performance FPGA-based peak detector is used for image pre-processing. In laser triangulation applications the 3D CMOS camera MV1-D2048x1088-3D03-160-G2-8 outputs the line position and qualification information to each line position value.

The camera is supported by the PF Suite 3D, a graphical user interface (GUI) for a quickly evaluation of the camera and a SDK for the implementation of the 3D CMOS camera. The following picture shows user interface of the PF Suite 3D.





Triangulation Rates

2048x1088 @ 340fps
2048x64 @ 4220fps
2048x32 @ 8450fps





Related Product: MV1-D1312-3D02-160-GB-12

DR1-D1312-200-G2-8 > Brochure

Photonfocus 1312x1082 DR1 Series monochrome CMOS camera, 135fps, global shutter, LinLog®, offset/gain correction, HIGH SPEED GigE interface with Photonfocus Double Speed technology, up to 8 bits per pixel.

ROI Frame Rates

544x544 @ 600fps
608x480 @ 612fps
672x480 @ 559fps

MV1-D2080-160-CL-12 > Brochure

Photonfocus 2080x2080 MV1 Series monochrome CMOS camera, 34fps, global shutter, LinLog®, offset/gain correction, Camera Link® base interface, 2 taps, 80MHz pixel clock, up to 12 bits per pixel.  F, C and M42 lens mount options.  Ask us about enhanced NIR D2080IE options.

MV1-D1312-CL Series > Brochure

Photonfocus 1312 x1082 MV1 Series monochrome CMOS camera, up to 108fps, global shutter, LinLog® high dynamic range, offset/gain correction, Camera Link® base interface, 2 taps, 80MHz pixel clock, up to 12 bits per pixel.  Ask about enhanced NIR D1312IE and color options.

Models: MV1-D1312-40-CL-12 | MV1-D1312-80-CL-12 | MV1-D1312-160-CL-12
MV1-D1312-240-CL-8



ROI Frame Rates (-240 model)

544x544 @ 713fps
608x480 @ 727fps
672x480 @ 665fps

ROI Frame Rates (-160 model)

544x544 @ 485fps
608x480 @ 495fps
672x480 @ 452fps

MV1-D1312-G2 Series > Brochure > NEW SMALLER FORM FACTOR!

Photonfocus 1312 x1082 MV1 G2 Series monochrome CMOS camera, up to 68fps, global shutter, LinLog® high dynamic range, offset/gain correction, GigE Vision interface, 2 taps, 50MHz pixel clock, up to 12 bits per pixel.  Ask about enhanced NIR D1312IE options.

Models: MV1-D1312-40-G2-12 | MV1-D1312-80-G2-12 | MV1-D1312-100-G2-12

SM2-D1312 Smart Camera Series > Brochure

Photonfocus 1312x1082 D1312 Smart Camera Series monochrome CMOS camera, built-in 1GHz TMS320 DSP, 256MB SDRAM, 2GB SD card, built-in web server, up to 108fps, global shutter, LinLog® high dynamic range, offset/gain correction, Gigabit Ethernet interface, 80MHz pixel clock, 2 taps, up to 12 bits per pixel.

Models: SM2-D1312-80-GB-12 | SM2-D1312-100-JPEG-GB-12 | SM2-D1312-160-GB-12

MV-D1024E Series > Brochure

Photonfocus 1024x1024 Enhanced Series monochrome CMOS camera, up to 150fps, global shutter, LinLog®, offset/gain correction, Camera Link® base interface, 80MHz pixel clock, 2 taps, 12 bits per pixel.

Models: MV-D1024E-40-CL-12 | MV-D1024E-80-CL-12 | MV-D1024E-160-CL-12



ROI Frame Rates (-160 model)

640x480 @ 503fps
512x512 @ 586fps
256x256 @ 2230fps
