Photonfocus 3D Cameras

3D measurement using structured light, a source projects a pattern of light and dark stripes onto the area being measured, which the CMOS camera then records using the principles of triangulation. During this procedure, the camera is fixed in a tilted position at a defined angle to the axis of projection. Any change to the stripe density and stripe shape can then be interpreted to represent the information on the 3D properties of the object being measured. Photonfocus offers a wide variety of 3D Line Profiling cameras.

MV1-D2048-3D04-760-G2 | BROCHURE

  • CMOSIS CMV4000, 1", 2048 x 2048, 7740fps, GigE Interface

MV1-D2048x1088-3D03-760-G2 | BROCHURE

  • CMOSIS CMV2000, 2/3", 2048 x 1088, 10200fps, GigE Interface

MV1-D2048x1088-3D03-760-G2-S10 | BROCHURE

  • CMOSIS CMV2000, 2/3", 2048 x 1088, 10200fps, GigE Interface

MV1-D1312-3D02-160-G2 | BROCHURE

  • Photonfocus A1312, 1", 1312 x 1082, 3000fps, GigE Interface

MV1-D1024E-3D02-160-G2 | BROCHURE

  • Photonfocus A1024, 1", 1024 x 1024, 6750fps, GigE Interface

MV-D1024E-3D01-160-CL | BROCHURE

  • Photonfocus A1024, 1", 1024 x 1024, 3100fps, Camera Link Interface
