The camera series MV1-D3360-G2 is based on the CMOSIS CMV8000 CMOS image sensor. The CMOSIS CMV8000 CMOS image sensors are optimized for low light conditions and is available as standard monochrome versions. The cameras have GigE Vision and Base Camera Link interface options.
These cameras focus on demanding applications in industrial image processing. They are optimized for low light applications. Due to the global shutter, even high-speed applications with exposure times in the µs-area are possible.
Photonfocus QR1-D2048x1088 Series
The Quad Rate camera series QR1-D2048x1088(I/C)-G2 is based on the CMOSIS CMV2000 CMOS image sensor. The CMOSIS CMV2000 CMOS image sensors are optimized for low light conditions and are available as standard monochrome, as NIR enhanced (I) and as colour (C) versions. The Quad-Rate cameras are 4 times faster than standard GigE cameras and use only one data cable (no link-aggregation). The cameras have the GigE interface (GigEVision).
Resolution Frame rate [fps]
2040 x 1088 @ 169
1024 x 1024 @ 358
800 x 600 @ 606
640 x 480 @ 754
Photonfocus MV1-D2048x1088-HS Series
The MV1-D2048x1088-HS01-G2 camera deploys the IMEC line scan wedge CMV2K-LS100-NIR sensor which is based on the CMOSIS CMV2000 CMOS image sensor. The sensor has in the spectral region from 600nm to 1000nm 100 pass bands with a Full-Width Half-Maximum (FWHM) of 10 - 12nm.
The MV1-D2048x1088-HS02-G2 camera deploys the IMEC snapshot mosaic CMV2K-SSM5x5-NIR sensor which is based on the CMOSIS CMV2000 CMOS image sensor. The sensor has in the spectral region from 600nm to 975nm 25 pass bands in a 5 by 5 mosaic with a Full-Width Half-Maximum (FWHM) of 16nm. The spatial resolution of the sensor is 409 x 217 pixels per spectral band.
The cameras focus on demanding hyperspectral imaging applications. The low full well capacity and the global shutter of the sensor make high speed applications possible. The camera has the GigE interface (GigEVision).
